BMG’s regional workshop in Riverhorse Valley, KwaZulu-Natal, plays a critical role in the sugar sector by providing engineering solutions designed to optimise productivity for sugar growers and millers.
“Our dedicated workshop, which focuses on core KZN divisions – including hydraulics and pneumatics, drives, chain, bearings, gaskets and materials handling – operates closely with 11 dedicated BMG KZN branches, to meet every customer’s specific requirement,” says Hylton Doyle, BMG’s Engineering Manager, KZN. “BMG’s specialist service centre, with assembly, repair, maintenance, and support operations, offers combined technical expertise and value–added product solutions. Benefits for customers include a dependable service, repair and delivery efficiencies, centralised technical support, and easy accessibility to BMG’s comprehensive range of quality branded engineering components.
“An important area of growth for BMG is in the sugar industry. The KZN field service team has been involved in several field service projects locally and in neighbouring states, during recent off-crop seasons, as well as dealing with urgent breakdowns in sugar mills and refineries.
“The workshop’s specialist services to the sugar sector include bearing and gearbox inspection, bearing and chain refurbishment, large-size bearing assembly and alignment and balancing. The team also works on shredder lube systems, juice heater door hydraulics, mill roll hydraulics, mill bearing lubrication, shredder hook bar removal systems, as well as many customised product designs.”
The BMG team has recently completed a refurbishment, fabrication, and replacement project to refurbish and replace worn components in preparation for high productivity in the upcoming season.
Dorstener gearboxes have been used successfully on many diffuser drives, mill drives and feeder tables for many years.
In spite of tight time restrictions before the seasonal start-up of the mill, coupled with manufacturing challenges, BMG has designed, fabricated and installed new carriers, reducing the normal 24-week delivery period to only four weeks, with cost savings of about 7,5 times that of the OEM.
Carriers are normally manufactured from cast iron, which is extremely difficult to repair. In this case, there was the additional problem of bores positioned close together, with virtually no wall thickness between the bearing journals, which was where the cracking had occurred. Because of the harsh operating conditions of the mill and the high torque load of these units, BMG specialists recommended replacement as the preferred option over refurbishment.
These planet carriers were re-engineered and fabricated out of 355WA steel plate, which is not only stronger than the original cast iron units but also allowed BMG to manufacture these carriers in a far shorter lead time of three weeks.
The team was on a tight deadline to have drawings and designs approved to ensure highly accurate dimensions for a perfect fit with clearances to accommodate the gear mesh.
Welding challenges to maintain the structural rigidity of the system were overcome by machining interlocking tabs in the top and bottom main plates, as well as in the webs and side rings, to ensure a more precise assembly for welding, with less distortion. The webs and side plates were welded to the bottom ring and the entire assembly was then fitted fit onto the top ring. Slots were later filled with weld so that the webs formed an integral part of the structure.
BMG’s total plant maintenance solutions are geared to optimise productivity and enhance process plant operating reliability to make a difference in the efficiencies of the sugar sector.
